TR-RELAYMON-2

The TR-RELAYMON-2 multi output-input module is designed for use with the Triga Series fire alarm control panels (FACPs).



The addressable module is intended for use in intelligent, two-wire loops. It includes two individual relay control modules and two Class B monitor modules. Each relay output is intended for Form C switching applications which do not require wiring supervision for the load circuit. Each monitor input provides an interface between a fire alarm control panel and one or more normally open contact-type devices. Each relay output has its own green LED.

Category:

Description

Addressable Dual Relay / Monitor Module



The TR-RELAYMON-2 multi output-input module is designed for use with the Triga Series fire alarm control panels (FACPs).



The addressable module is intended for use in intelligent, two-wire loops. It includes two individual relay control modules and two Class B monitor modules. Each relay output is intended for Form C switching applications which do not require wiring supervision for the load circuit. Each monitor input provides an interface between a fire alarm control panel and one or more normally open contact-type devices. Each relay output has its own green LED.



INSTALLATION
The TR-RELAYMON-2 mounts directly into a 4” square electrical box. The box must have a minimum depth of 2-1/8”. A surface mount electrical box (TR-SMB500) is available from Triga.



COMPATIBILITY
The TR-REALYMON-2 is compatible with the following Triga Series FACPs:
• TR-2100R / ITR-2100B
• TR-2100ECSR / TR-2100ECSB
• TR-R2100R / TR-R2100B

Features & Benefits

• Monitor two circuits, with unique addresses, simultaneously
• Two Form C relay contacts with each having a unique address
• Fully supervised support for Class B input wiring
• Relay programming is completely flexible –can be mapped to zone conditions
• Individual LEDs for each monitored input and relay output
• Rotary address switches for fast installation
• SEMS screws for easy wiring
• UL Listed
• FM Approved

Technical Specifications

SPECIFICATIONS
Physical: 4.675″H x 4.275″W x 1.4″D (mounts to a 4″ square by 2 1/8″ deep box).
Shipping Weight: 6.3oz (196g)



ELECTRICAL RATINGS
Operating Voltage: 15 to 32VDC
Standby & Alarm Current: 1.3mA



ENVIRONMENTAL
Operating Temperature: 32º-120ºF (0ºC – 49ºC) Humidity: 10 to 93% non-condensing)



RELAY CONTACT RATINGS
[table “” not found /]




ORDERING INFORMATION
TR-RELAYMON-2: Relay/Monitor module



ACCESSORIES
TR-SMB500: 4” square surface mount electrical box
